X-Y-Z axis system

Optimise your soldering process with our X-Y-Z axis system

X-Y-Z axis systems are important for the automation of manufacturing processes as they enable flexible movement in three-dimensional space.

Benefit

With the X-Y-Z axis system, all positions on the assembly can be approached in three-dimensional space. The axis system can be used both for transporting the assembly and for positioning process modules.

Performance

The X-Y-Z axis system plays a central role in the automation of selective soldering processes at EUTECT. As it enables precise movements in three dimensions, all areas within a process cell can be reached with high accuracy. This flexibility is crucial in selective soldering technology, as different soldering modules or assemblies have to be positioned precisely depending on the requirements. The X-Y-Z axis systems used are suitable both for transporting workpieces and for positioning process modules, ensuring high process stability and repeat accuracy.

Flexibility

Ein wesentlicher Vorteil eines X-Y-Z- Achsensystems ist die individuelle Anpassbarkeit. Der Verfahrbereich der Achsen lässt sich anhand der EUTECT-Software exakt definieren. Die Reichweite der Achsen wird wiederum genau auf die Anforderungen des jeweiligen Lötprozesses abgestimmt. Die Z-Achse, die sich vertikal bewegt, lässt sich mit verschiedenen Modulen ausstatten. Drahtvorschübe, Laserköpfe oder Lötkolben erlauben es, unterschiedliche Lötmethoden wieLaser-,Induktions-oderKolbenlötendurchzuführen. Aber auchThermoden-bzw.Laser Knife-Module können bestückt werden. Darüber hinaus ermöglicht das System den präzisen Transport einzelner Baugruppen oder eines kompletter Werkstückträger zu den entsprechenden Prozessstationen.

Product highlights

Free movement in three-dimensional space
Travelling range individually definable
Customised module assembly of the Z-axis
Reliable and precise positioning for high reproducibility

Versatility

Thanks to the modular machine concept of the EUTECT, it is possible to operate different production environments with the X-Y-Z system. Whether in stand-alone applications, rotary indexing systems or as part of in-line production - the flexibility of the system allows efficient customisation to specific customer requirements. The modular EUTECT system supports this versatility and enables the customised configuration of different production processes. As the individual modules are optimally matched to each other, the highest possible throughput and best process quality can be guaranteed.

Would you like to find out more?

Why EUTECT?

EUTECT attaches great importance to the integration of customised solutions that have a very high customer benefit. Each automation solution is customised to ensure optimum production performance. In addition, the in-house software supports customised solutions. This enables precise control and monitoring of the axis system, significantly increasing the efficiency and precision of the soldering processes.

The X-Y-Z axis systems used by EUTECT can also be customised for complex assemblies that cannot be processed with standard soldering systems. It is possible to position soldering modules precisely and set different process parameters flexibly and individually. This is particularly advantageous in modern electronics production, where ever smaller and more complex components have to be soldered.

The X-Y-Z axis system is an indispensable component in EUTECT's modern selective soldering technology. It offers the necessary flexibility and precision to efficiently handle even complex soldering tasks. Thanks to its modularity and adaptability, the system is suitable for various process environments. This makes it the ideal solution for companies looking for customised automation solutions.
